Diffraction project datasets IDP02536_3kuu
- Method: SAD
- Resolution: 1.41 Å
- Space group: I 4 2 2
PDB website for 3KUU
PDB validation report for 3KUU
doi:10.18430/m33kuu
Project details
| Title | Structure of the PurE Phosphoribosylaminoimidazole Carboxylase Catalytic Subunit from Yersinia pestis |
| Authors | Anderson, S.M., Wawrzak, Z., Brunzelle, J.S., Onopriyenko, O., Kwon, K., Edwards, A., Savchenko, A., Anderson, W.F., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.15 / 0.17 |
| Unit cell edges [Å] | 114.04 x 114.04 x 231.74 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset idp02536-1a_A.### details
| Number of frames | 240 (1 - 240) |
| Distance [mm] | 190.0 |
| Oscillation width [°] | 0.75 |
| Phi [°] | 90.0 |
| Wavelength [Å] | 0.97857 |
| Experiment Date | 2009-11-12 |
| Equipment | 21-ID-D at APS (Advanced Photon Source) |
Dataset idp02536-1a_B.### details
| Number of frames | 240 (1 - 240) |
| Distance [mm] | 190.0 |
| Oscillation width [°] | 0.75 |
| Phi [°] | 270.0 |
| Wavelength [Å] | 0.97857 |
| Experiment Date | 2009-11-12 |
| Equipment | 21-ID-D at APS (Advanced Photon Source) |
Dataset idp02536-3.### details
| Number of frames | 360 (1 - 360) |
| Distance [mm] | 140.0 |
| Oscillation width [°] | 0.30 |
| Phi [°] | 110.0 |
| Wavelength [Å] | 1.12718 |
| Experiment Date | 2009-11-13 |
| Equipment | 21-ID-D at APS (Advanced Photon Source) |
Dataset idp02536-3_hr.### details
| Number of frames | 154 (1 - 154) |
| Distance [mm] | 110.0 |
| Oscillation width [°] | 0.25 |
| Wavelength [Å] | 1.12719 |
| Experiment Date | 2009-11-13 |
| Equipment | 21-ID-D at APS (Advanced Photon Source) |
Dataset idp02536-3_lr.### details
| Number of frames | 180 (1 - 180) |
| Distance [mm] | 240.0 |
| Oscillation width [°] | 0.60 |
| Phi [°] | 110.0 |
| Wavelength [Å] | 1.12719 |
| Experiment Date | 2009-11-13 |
| Equipment | 21-ID-D at APS (Advanced Photon Source) |
