Diffraction project datasets IDP91947_4oen
- Method: Molecular Replacement
- Resolution: 1.65 Å
- Space group: P 1 21 1
PDB website for 4OEN
PDB validation report for 4OEN
doi:10.18430/m34oen
Project details
| Title | Crystal structure of the second substrate binding domain of a putative amino acid ABC transporter from Streptococcus pneumoniae Canada MDR_19A |
| Authors | Stogios, P.J., Wawrzak, Z., Kudritska, M., Yim, V., Savchenko, A., Anderson, W.F., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.16 / 0.20 |
| Unit cell edges [Å] | 42.43 x 109.61 x 57.92 |
| Unit cell angles [°] | 90.0, 111.1, 90.0 |
Dataset IDP91947-1.### details
| Number of frames | 300 (1 - 300) |
| Distance [mm] | 160.0 |
| Oscillation width [°] | 0.60 |
| Phi [°] | 60.0 |
| Wavelength [Å] | 0.97872 |
| Experiment Date | 2013-12-11 |
| Equipment | 21-ID-F at APS (Advanced Photon Source) |
Dataset IDP91947-1b.### details
| Number of frames | 100 (1 - 100) |
| Distance [mm] | 160.0 |
| Oscillation width [°] | 0.60 |
| Phi [°] | 180.0 |
| Wavelength [Å] | 0.97872 |
| Experiment Date | 2013-12-11 |
| Equipment | 21-ID-F at APS (Advanced Photon Source) |
