Diffraction project datasets 8r5r
- Resolution: 3.078 Å
- Space group: P 21 21 21
Uniprot website for P48775
PDB website for 8R5R
PDB validation report for 8R5R
doi:10.18430/m38r5r
Project details
| Title | Structure of apo TDO with a bound inhibitor |
| Authors | Wicki, M., Mac Sweeney, A. |
| R / Rfree | 0.23 / 0.25 |
| Unit cell edges [Å] | 91.74 x 132.91 x 137.50 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset D5-33805_1_1_master.h5@##### details
| Number of frames | 1080 (1 - 1080) |
| Distance [mm] | 389.4 |
| Oscillation width [°] | 0.25 |
| Omega [°] | 105.0 |
| Wavelength [Å] | 0.88560 |
| Equipment | ID23-1 at ESRF (European Synchrotron Radiation Facility) |
