Diffraction project datasets IDP00038_3gjz
- Method: SAD
- Resolution: 2.1 Å
- Space group: P 43
PDB website for 3GJZ
PDB validation report for 3GJZ
doi:10.18430/m33gjz
Project details
| Title | Crystal structure of microcin immunity protein MccF from Bacillus anthracis str. Ames |
| Authors | Nocek, B., Zhou, M., Kwon, K., Anderson, W., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.19 / 0.23 |
| Unit cell edges [Å] | 118.96 x 118.96 x 55.54 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset peak-1.####.img details
| Number of frames | 399 (2 - 400) |
| Distance [mm] | 309.8 |
| Oscillation width [°] | 0.40 |
| Omega [°] | -89.6 |
| Kappa / Chi [°] | 0.0003 |
| Phi [°] | -0.007 |
| Wavelength [Å] | 0.97918 |
| Experiment Date | 2008-12-02 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
