Diffraction project datasets IDP00038_4mi1
- Resolution: 1.4 Å
- Space group: P 43
PDB website for 4MI1
PDB validation report for 4MI1
doi:10.18430/m34mi1
Project details
| Title | Crystal structure of the double mutant (S112A, H303A) of B.anthracis mycrocine immunity protein (MccF) with aspartyl sulfamoyl adenylates |
| Authors | Nocek, B., Severinov, K., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.13 / 0.16 |
| Unit cell edges [Å] | 117.89 x 117.89 x 55.98 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset xtal1-M1E11_ASA.####.img details
| Number of frames | 120 (1 - 120) |
| Distance [mm] | 110.0 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -45.0 |
| Kappa / Chi [°] | 0.0001 |
| Phi [°] | -0.0033 |
| Wavelength [Å] | 0.97918 |
| Experiment Date | 2012-10-22 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
Dataset xtal1-M1E11_ASA_dataset2.####.img details
| Number of frames | 100 (1 - 100) |
| Distance [mm] | 181.7 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -45.0 |
| Kappa / Chi [°] | 0.0001 |
| Phi [°] | -0.0033 |
| Wavelength [Å] | 0.97918 |
| Experiment Date | 2012-10-22 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
Dataset xtal1-M1E11_ASA_dataset2_hr.####.img details
| Number of frames | 120 (1 - 120) |
| Distance [mm] | 119.4 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -45.0 |
| Kappa / Chi [°] | 0.0001 |
| Phi [°] | -0.0033 |
| Wavelength [Å] | 0.97918 |
| Experiment Date | 2012-10-22 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
