Diffraction project datasets IDP02082_3q7h
- Method: SAD
- Resolution: 2.5 Å
- Space group: P 1 21 1
PDB website for 3Q7H
PDB validation report for 3Q7H
doi:10.18430/m33q7h
Project details
| Title | Structure of the ClpP subunit of the ATP-dependent Clp Protease from Coxiella burnetii |
| Authors | Anderson, S.M., Wawrzak, Z., Gordon, E., Hasseman, J., Anderson, W.F., Savchenko, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.17 / 0.21 |
| Unit cell edges [Å] | 101.91 x 137.47 x 127.78 |
| Unit cell angles [°] | 90.0, 109.0, 90.0 |
Dataset idp02082-n1_A.### details
| Number of frames | 270 (1 - 270) |
| Distance [mm] | 300.0 |
| Oscillation width [°] | 0.75 |
| Wavelength [Å] | 0.97920 |
| Experiment Date | 2009-12-10 |
| Equipment | 21-ID-D at APS (Advanced Photon Source) |
Dataset idp02082-n1_B.### details
| Number of frames | 270 (1 - 270) |
| Distance [mm] | 300.0 |
| Oscillation width [°] | 0.75 |
| Phi [°] | 180.0 |
| Wavelength [Å] | 0.97920 |
| Experiment Date | 2009-12-10 |
| Equipment | 21-ID-D at APS (Advanced Photon Source) |
