Diffraction project datasets IDP02454_3m49
- Method: SAD
- Resolution: 2.0 Å
- Space group: P 21 21 21
PDB website for 3M49
PDB validation report for 3M49
doi:10.18430/m33m49
Project details
| Title | Crystal Structure of Transketolase Complexed with Thiamine Diphosphate from Bacillus anthracis |
| Authors | Maltseva, N., Kim, Y., Kwon, K., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.14 / 0.17 |
| Unit cell edges [Å] | 83.33 x 132.09 x 137.32 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset INDF7-gly1-peak.####.img details
| Number of frames | 220 (1 - 220) |
| Distance [mm] | 180.0 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -110.0 |
| Kappa / Chi [°] | 0.0003 |
| Phi [°] | -0.0009 |
| Wavelength [Å] | 0.97942 |
| Experiment Date | 2009-07-12 |
| Equipment | 19-BM at APS (Advanced Photon Source) |
