Diffraction project datasets IDP04645_4ma0
- Resolution: 1.982 Å
- Space group: P 43 21 2
PDB website for 4MA0
PDB validation report for 4MA0
doi:10.18430/m34ma0
Project details
| Title | The crystal structure of phosphoribosylaminoimidazole carboxylase ATPase subunit of Francisella tularensis subsp. tularensis SCHU S4 in complex with partially hydrolysed ATP |
| Authors | Tan, K., Zhou, M., Kwon, K., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.19 / 0.24 |
| Unit cell edges [Å] | 84.86 x 84.86 x 104.26 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset IDP01765GMP_B.####.img details
| Number of frames | 180 (1 - 180) |
| Distance [mm] | 182.8 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -60.0 |
| Wavelength [Å] | 0.97927 |
| Experiment Date | 2013-08-09 |
| Equipment | 19-BM at APS (Advanced Photon Source) |
