Diffraction project datasets IDP05591_4pz0
- Resolution: 1.25 Å
- Space group: P 1 21 1
PDB website for 4PZ0
PDB validation report for 4PZ0
doi:10.18430/m34pz0
Project details
| Title | The crystal structure of a solute binding protein from Bacillus anthracis str. Ames in complex with quorum-sensing signal autoinducer-2 (AI-2) |
| Authors | Tan, K., Gu, M., Kwon, K., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.13 / 0.15 |
| Unit cell edges [Å] | 39.01 x 58.07 x 63.19 |
| Unit cell angles [°] | 90.0, 95.6, 90.0 |
Dataset TIDP5591B_PKa.####.img details
| Number of frames | 30 (1 - 30) |
| Distance [mm] | 145.0 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -120.0 |
| Kappa / Chi [°] | 0.0003 |
| Phi [°] | 39.9831 |
| Wavelength [Å] | 0.97926 |
| Experiment Date | 2012-08-22 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
Dataset TIDP5591_PKa.####.img details
| Number of frames | 210 (1 - 210) |
| Distance [mm] | 145.0 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -90.0 |
| Kappa / Chi [°] | 0.0003 |
| Phi [°] | 39.9831 |
| Wavelength [Å] | 0.97926 |
| Experiment Date | 2012-08-22 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
