Diffraction project datasets IDP06102_5euf
- Resolution: 2.8 Å
- Space group: C 1 2 1
PDB website for 5EUF
PDB validation report for 5EUF
doi:10.18430/m35euf
Project details
| Title | The crystal structure of a protease from Helicobacter pylori |
| Authors | Tan, K., Zhou, M., Kwon, K., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.19 / 0.24 |
| Unit cell edges [Å] | 155.16 x 50.27 x 147.89 |
| Unit cell angles [°] | 90.0, 94.9, 90.0 |
Dataset IDP06102_INa_B.####.img details
| Number of frames | 240 (1 - 240) |
| Distance [mm] | 344.1 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -170.0 |
| Wavelength [Å] | 0.97940 |
| Experiment Date | 2014-12-05 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
Dataset IDP06102_PKa_B.####.img details
| Number of frames | 240 (1 - 240) |
| Distance [mm] | 344.5 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -170.0 |
| Wavelength [Å] | 0.97918 |
| Experiment Date | 2014-12-05 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
