Diffraction project datasets IDP90790_3q3w
- Method: Molecular Replacement
- Resolution: 1.89 Å
- Space group: P 21 21 2
PDB website for 3Q3W
PDB validation report for 3Q3W
doi:10.18430/m33q3w
Project details
| Title | Isopropylmalate isomerase small subunit from Campylobacter jejuni. |
| Authors | Osipiuk, J., Gu, M., Papazisi, L., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.19 / 0.23 |
| Unit cell edges [Å] | 74.50 x 151.94 x 32.72 |
| Unit cell angles [°] | 90.0, 90.0, 90.0 |
Dataset idp90790_3Q3W.####.img details
| Number of frames | 140 (1 - 140) |
| Distance [mm] | 265.5 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -20.0 |
| Kappa / Chi [°] | 0.0001 |
| Phi [°] | 34.9861 |
| Wavelength [Å] | 0.97921 |
| Experiment Date | 2009-12-10 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
Dataset idp90790_3Q3W.####.img details
| Number of frames | 35 (301 - 335) |
| Distance [mm] | 265.5 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -50.0 |
| Kappa / Chi [°] | 0.0003 |
| Phi [°] | 34.9861 |
| Wavelength [Å] | 0.97921 |
| Experiment Date | 2009-12-10 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
Dataset idp90790_3Q3W.####.img details
| Number of frames | 80 (401 - 480) |
| Distance [mm] | 265.5 |
| Oscillation width [°] | 0.50 |
| Omega [°] | 45.0 |
| Kappa / Chi [°] | 0.0003 |
| Phi [°] | 34.9861 |
| Wavelength [Å] | 0.97921 |
| Experiment Date | 2009-12-10 |
| Equipment | 19-ID at APS (Advanced Photon Source) |
