Diffraction project datasets IDP90895_3os4
- Method: SAD
- Resolution: 1.601 Å
- Space group: P 1
PDB website for 3OS4
PDB validation report for 3OS4
doi:10.18430/m33os4
Project details
| Title | The Crystal Structure of Nicotinate Phosphoribosyltransferase from Yersinia pestis |
| Authors | Maltseva, N., Kim, Y., Gu, M., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID) |
| R / Rfree | 0.16 / 0.19 |
| Unit cell edges [Å] | 47.39 x 50.68 x 87.18 |
| Unit cell angles [°] | 82.0, 83.4, 72.0 |
Dataset INDG10glyc-peak.####.img details
| Number of frames | 240 (1 - 240) |
| Distance [mm] | 160.0 |
| Oscillation width [°] | 1.00 |
| Omega [°] | -120.0 |
| Kappa / Chi [°] | 0.0003 |
| Phi [°] | -0.0009 |
| Wavelength [Å] | 0.97926 |
| Experiment Date | 2010-08-09 |
| Equipment | 19-BM at APS (Advanced Photon Source) |
