Diffraction project datasets TrpaC_01302_a_B1-ADP_39ac
- Resolution: 2.49 Å
- Space group: P 1
Uniprot website for O83974
PDB website for 39AC
PDB validation report for 39AC
doi:10.18430/M339AC
Project details
| Title | Crystal structure of a Nucleoside diphosphate kinase from Treponema pallidum (ADP complex) |
| Authors | Seattle Structural Genomics Center for Infectious Disease (SSGCID) |
| R / Rfree | 0.21 / 0.26 |
| Unit cell edges [Å] | 115.79 x 115.86 x 128.60 |
| Unit cell angles [°] | 90.1, 106.4, 119.9 |
Dataset PSL-1603_3613_master.h5@##### details
| Number of frames | 1800 (1 - 1800) |
| Distance [mm] | 200.0 |
| Oscillation width [°] | 0.20 |
| Wavelength [Å] | 0.97860 |
| Equipment | 19-ID 2 at NSLS II (National Synchrotron Light Source II) |
